C12200 Copper Strip is a phosphorus-deoxidized copper material known for its excellent corrosion resistance, good electrical conductivity, and reliable fabrication performance. It provides dependable long-term performance in demanding industrial environments while maintaining excellent forming and joining characteristics.
Widely used in industrial components, engineering equipment, precision fabricated parts, and applications requiring durability, corrosion resistance, and service reliability.
C12200 copper strip (UNS C12200 copper alloy strip, DHP high-phosphorus deoxidized copper tape, Cu-DHP bright annealed copper ribbon, CW024A slit strip coil, and fine gauge transformer copper foil) is manufactured through continuous casting, precision cold tandem rolling, and bright protective atmosphere annealing to deliver outstanding electrical and thermal conductivity, excellent deep drawing capability, superior brazing weldability, and 100% resistance to high-temperature hydrogen embrittlement. Engineered for electrical transformer foil windings, coaxial cable shielding wrap, HVAC heat exchanger fins, automotive radiator tanks, and electronic lead frames, C12200 copper strip provides uniform thickness tolerances and smooth burr-free slit edges.
At XQJ Metal, we operate ultra-precision multi-roll cold rolling mills, automated high-speed precision gang slitting lines, optical edge profilers, and bell-type bright hydrogen annealing furnaces to produce premium C12200 copper strip products conforming strictly to global engineering standards, including ASTM B152 (standard specification for copper sheet, strip, plate, and rolled bar), ASTM B888, EN 1652 (Cu-DHP / CW024A), JIS H3100 (C1220), and GB/T 2059 (TP2) specifications. We offer complete strip thicknesses from 0.05mm to 3.0mm (0.002 inch to 0.120 inch), slit widths from 5mm to 600mm (0.2 inch to 24 inches), inner coil diameters (ID 75mm, 100mm, 150mm, 300mm, 400mm, 508mm), and custom tempers ranging from dead soft annealed to spring hard.
| Temper Designation | Standard Code & State | Thickness Range (mm / inch) | Tensile Strength (MPa) | Elongation (% in 50mm) | Primary Industrial Applications |
| Soft Annealed (O60) | ASTM B152 UNS C12200 O60 | 0.05mm to 3.0mm (0.002″ – 0.120″) | 200 to 260 MPa | ≥ 35% | Electrical transformer foil windings, deep-drawn radiator caps, flexible connectors & HVAC heat exchanger fins |
| Quarter Hard (H01) | ASTM B152 UNS C12200 H01 | 0.10mm to 2.5mm (0.004″ – 0.100″) | 240 to 300 MPa | ≥ 25% | Coaxial cable shielding wrap, telecommunication grounding tapes & shallow stamped electrical contacts |
| Half Hard (H02) | ASTM B152 UNS C12200 H02 | 0.15mm to 2.0mm (0.006″ – 0.080″) | 270 to 340 MPa | ≥ 12% | Automotive radiator header plates, electrical switch terminals, terminal clips & copper gaskets |
| Full Hard (H04) | ASTM B152 UNS C12200 H04 | 0.20mm to 1.5mm (0.008″ – 0.060″) | 330 to 410 MPa | ≥ 4% | High-spring electrical terminals, burst diaphragms, metallic seals & wear-resistant electronic shims |
Understanding the key metallurgical properties of C12200 copper strip (Phosphorus Deoxidized High Residual) allows transformer manufacturers and coil winders to optimize electrical efficiency and joinability:
To eliminate coil winding jams and ensure smooth feeding into high-speed automated stamping presses, XQJ Metal applies strict slitting and edge finishing protocols for C12200 copper strip orders:
Our versatile C12200 copper strip products serve as fundamental conductive and thermal elements across global industries:
To ensure flawless surface cleanliness, uniform mechanical tempers, and corrosion-free international transit, XQJ Metal enforces strict Quality Control (QC) standards on every C12200 copper strip shipment:
Q1: What is the primary advantage of C12200 copper strip compared to C11000 for transformer windings?
A: C12200 is phosphorus deoxidized (Cu-DHP), making it completely immune to hydrogen embrittlement during high-temperature brazing of transformer leads. It also offers exceptional edge burr control and smooth ductility during tight automated foil winding.
Q2: Can XQJ Metal supply ultra-thin C12200 copper strip with rounded deburred edges for cable shielding?
A: Yes, we provide precision slitting down to 0.05mm thickness and 5mm width, with custom deburred or rounded safety edges to prevent cutting or tearing cable insulation jackets during high-speed wrapping.
To request real-time FOB/CIF spot prices, coil weight calculators, or sample strips for C12200 copper strip, Contact Our Copper Engineering Team today.
Our materials support a wide range of construction and infrastructure projects
C12200 copper strip is a phosphorus-deoxidized copper alloy with a slightly higher phosphorus content than C12000, providing improved weldability and brazing performance while maintaining excellent corrosion resistance and thermal conductivity. The appropriate grade should be selected according to the fabrication process and service requirements.
C12200 copper strip offers excellent dimensional consistency, good ductility, and dependable fabrication performance, making it well suited for continuous stamping, bending, forming, and other high-volume manufacturing processes.
C12200 copper strip combines reliable conductivity, corrosion resistance, and stable forming performance, making it an excellent material for electrical connectors, terminals, shielding parts, heat transfer components, and other precision-fabricated industrial products.
It offers excellent resistance to seawater corrosion and maintains strength in humid and salt-rich conditions.
No. Strength is achieved through strain hardening rather than heat treatment.
Yes. It provides excellent weldability for structural fabrication.
Yes, it is commonly applied in tanks and pressure equipment.
Yes. It provides higher strength compared with most non-heat-treated aluminum alloys.
Yes. Thickness, width and temper can be adjusted based on project demand.
