C12200 Copper Sheet is a phosphorus-deoxidized copper material known for its excellent corrosion resistance, good electrical conductivity, and reliable fabrication performance. It provides dependable long-term performance in demanding industrial environments while maintaining excellent forming and joining characteristics.
Widely used in industrial equipment, engineering components, heat transfer systems, and applications requiring durability, corrosion resistance, and service reliability.
C12200 copper sheet (UNS C12200 copper plate, DHP high-phosphorus deoxidized copper panel, Cu-DHP bright annealed copper sheet metal, CW024A heavy plate, and architecturally polished copper sheet) is produced through advanced continuous casting, hot breakdown rolling, precision cold finishing, and bright protective atmosphere annealing. Engineered for HVAC refrigeration headers, solar collector heat absorption panels, architectural standing-seam roofing, underground earthing plates, chemical vessels, and heavy electrical bus bars, C12200 copper sheet offers superior ductility, excellent cold formability, 100% immunity to hydrogen embrittlement during high-temperature brazing, and exceptional long-term atmospheric corrosion resistance.
At XQJ Metal, we operate wide-width heavy plate rolling mills, precision hydraulic shearing lines, laser cutting systems, and bell-type bright hydrogen annealing furnaces to manufacture premium C12200 copper sheet and plate products conforming strictly to global engineering standards, including ASTM B152 (standard specification for copper sheet, strip, plate, and rolled bar), ASTM B370 (architectural copper sheet), EN 1652 (Cu-DHP / CW024A), JIS H3100 (C1220), and GB/T 2059 (TP2) specifications. We offer complete thickness options from 0.5mm to 50mm (0.020 inch to 2.0 inches), standard sheet dimensions of 1000x2000mm, 1220x2440mm (4×8 ft), and 1250x3000mm, as well as custom cut-to-size plates and custom tempers ranging from dead soft annealed to spring hard.
| Temper Designation | Standard Code & State | Thickness Range (mm / inch) | Tensile Strength (MPa) | Elongation (% in 50mm) | Primary Engineering Applications |
| Soft Annealed (O60) | ASTM B152 UNS C12200 O60 | 0.5mm to 20mm (0.020″ – 0.787″) | 200 to 260 MPa | ≥ 35% | Complex deep-drawn vessels, HVAC end plates, architectural flashing, roofing standing seams & formed gaskets |
| Half Hard (H02) | ASTM B152 UNS C12200 H02 | 0.8mm to 30mm (0.031″ – 1.181″) | 270 to 340 MPa | ≥ 15% | Electrical cabinet mounting plates, structural heat sink panels, transformer terminal sheets & flange shims |
| Full Hard (H04) | ASTM B152 UNS C12200 H04 | 1.0mm to 12mm (0.039″ – 0.472″) | 330 to 410 MPa | ≥ 5% | High-rigidity wear plates, spring contacts, structural electrical spacers & heavy mechanical retainers |
| As-Rolled Heavy Plate (M20) | ASTM B152 UNS C12200 Heavy Plate | 10mm to 50mm (0.394″ – 1.968″) | 220 to 300 MPa | ≥ 30% | Chemical reactor linings, heavy grounding electrodes, power station connection plates & marine sea chests |
Selecting the optimal copper alloy grade is critical for high-temperature joining, chemical resistance, and long-term structural integrity. C12200 copper sheet offers distinctive metallurgical advantages over standard electrolytic tough pitch copper (C11000):
To reduce jobsite labor and accelerate production lines, XQJ Metal delivers comprehensive value-added custom processing for C12200 copper sheet orders:
Our heavy-duty C12200 copper sheet and plate products are widely specified across major global construction and industrial manufacturing sectors:
To guarantee strict chemical composition, uniform mechanical temper, and pristine surface quality, XQJ Metal applies rigorous Quality Assurance (QA) protocols for every C12200 copper sheet shipment:
Q1: What is the primary difference between C12200 and C11000 copper sheet for roofing and HVAC?
A: C12200 is phosphorus deoxidized (Cu-DHP), making it completely immune to hydrogen embrittlement during high-temperature brazing and torch welding. While C11000 offers slightly higher electrical conductivity (100% IACS vs 85% IACS), C12200 is preferred for HVAC fabrication and architectural welding due to its superior joining characteristics.
Q2: Can XQJ Metal supply custom-sized C12200 copper plates with protective film on both sides?
A: Yes, we offer precision waterjet and laser cutting services to supply C12200 copper plates cut to your exact CAD dimensions, protected with heavy-duty 80-micron PE film on both sides to prevent scratching during handling and installation.
To request real-time FOB/CIF spot prices, plate weight calculators, or CAD fabrication quotes for C12200 copper sheet, Contact Our Copper Engineering Team today.
Our materials support a wide range of construction and infrastructure projects
C12200 copper sheet is a phosphorus-deoxidized copper alloy with a slightly higher phosphorus content than C12000, providing improved weldability and brazing performance while maintaining excellent corrosion resistance and thermal conductivity. The appropriate grade should be selected according to the fabrication process and service requirements.
C12200 copper sheet offers excellent weldability, corrosion resistance, and reliable fabrication performance, making it a preferred material for heat exchangers, pressure equipment, industrial enclosures, and other fabricated components that require dependable long-term service.
C12200 copper sheet provides reliable joint performance, good corrosion resistance, and stable mechanical properties after fabrication, helping extend the service life of components operating in demanding industrial environments.
It offers excellent resistance to seawater corrosion and maintains strength in humid and salt-rich conditions.
No. Strength is achieved through strain hardening rather than heat treatment.
Yes. It provides excellent weldability for structural fabrication.
Yes, it is commonly applied in tanks and pressure equipment.
Yes. It provides higher strength compared with most non-heat-treated aluminum alloys.
Yes. Thickness, width and temper can be adjusted based on project demand.
