5083 aluminum sheet belongs to the 5000 series Al-Mg alloy family. It offers exceptional corrosion resistance, high mechanical strength, and excellent weldability.
The alloy performs reliably in marine, transportation, and industrial applications exposed to seawater, harsh environments, or low temperatures. Its combination of strength and durability makes it one of the most widely used marine-grade aluminum alloys.
5083 aluminum sheet is a high-strength non-heat treatable Al-Mg-Mn alloy renowned for its exceptional corrosion resistance in marine and chemical environments. It provides outstanding fatigue strength, superior weldability, and excellent mechanical performance at cryogenic temperatures, making it a critical material for heavy-duty structural engineering.
At XQJ Metal, we process and supply certified 5083 aluminum sheets manufactured under strict quality systems in accordance with ASTM B209 and EN 485. We offer custom shearing, cut-to-size dimensions, and protective laser film application for global industrial clients.
| Parameter | Standard Value / Specification |
| Alloy & Temper | 5083 / O, H111, H112, H116, H321 |
| Thickness Range | 0.5mm – 200mm (Sheet & Heavy Plate) |
| Width Range | 1000mm, 1220mm, 1500mm, 2000mm, or Custom Sheared |
| Length Range | 2000mm, 2440mm, 3000mm, 6000mm, or Custom Cut |
| International Standards | ASTM B209, EN 485, EN 573, GB/T 3880, DNV/ABS Marine Certified |
| Surface Processing | Mill Finish, Anodizing Quality, Single/Double PE or Laser PVC Protective Film |
Q1: What is the difference between 5083 H116 and H321 tempers?
A: Both H116 and H321 tempers are specifically developed for marine applications, offering superior resistance to intergranular corrosion and exfoliation corrosion.
Q2: What is your Minimum Order Quantity (MOQ) for 5083 aluminum sheet?
A: Our standard MOQ is 1 metric ton per size. Small trial orders or cut-to-length samples can be arranged for standard stock items.
Q3: Can you provide laser-safe PVC film for CNC cutting?
A: Yes, we apply high-quality single-sided or double-sided PE or laser-safe PVC protective film to protect the sheet surface during laser cutting and bending.
If you require specific tempers, thick plate cutting, or technical material datasheets, explore our full range of Aluminum Sheet Products or Contact Our Sales Team directly for a fast factory-direct quote.
Our materials support a wide range of construction and infrastructure projects
5083 aluminum sheet provides higher strength than 5052 while maintaining excellent corrosion resistance and weldability. It is commonly selected for demanding structural applications where greater mechanical performance is required.
5083 aluminum sheet combines high strength with excellent weldability and resistance to seawater corrosion, making it a preferred material for welded structures used in marine, offshore, and heavy industrial applications.
5083 aluminum sheet is commonly selected when high strength, reliable welding performance, and excellent corrosion resistance are required. The final material selection should always be based on the structural design, service environment, and mechanical requirements.
It offers excellent resistance to seawater corrosion and maintains strength in humid and salt-rich conditions.
No. Strength is achieved through strain hardening rather than heat treatment.
Yes. It provides excellent weldability for structural fabrication.
Yes, it is commonly applied in tanks and pressure equipment.
Yes. It provides higher strength compared with most non-heat-treated aluminum alloys.
Yes. Thickness, width and temper can be adjusted based on project demand.
