C12000 Copper Sheet is a phosphorus-deoxidized copper material offering good thermal conductivity, corrosion resistance, and enhanced welding and brazing performance. It provides reliable fabrication characteristics for industrial applications requiring durable and efficient copper components.
Widely used in heat transfer equipment, fabricated parts, industrial components, and engineering applications requiring dependable joining performance and long-term service reliability.
C12000 copper sheet (also known as DHP copper sheet, Phosphorus-Deoxidized C12000 plate, or CDA 120 copper strip) is a specialized high-purity copper alloy engineered for outstanding weldability, excellent brazing performance, and superior corrosion resistance. Containing a minimum copper purity of 99.90% with controlled residual phosphorus (0.015%–0.040%), C12000 copper sheet completely eliminates the risk of hydrogen embrittlement during high-temperature welding or brazing operations.
At XQJ Metal, we manufacture and supply premium C12000 copper sheets, plates, and coils across various tempers and custom dimensions. Produced in full compliance with ASTM B152, ASTM B272, and EN 1652 standards, our DHP copper sheets undergo precision rolling and bright annealing to ensure clean surface finishes, tight thickness tolerances, and excellent formability.
| Parameter | Standard Value / Specification |
| Material Grade | C12000 / CDA 120 / DHP (Phosphorus-Deoxidized Copper) |
| Copper Purity (Cu) | ≥ 99.90% (Phosphorus Content: 0.015% – 0.040%) |
| Thermal Conductivity | High Thermal Transfer Efficiency |
| Thickness Range | 0.3mm – 50.0mm (Thin Sheet, Heavy Plate & Coil) |
| Standard Widths | 100mm – 1250mm (Custom Shearing Available) |
| Tempers Available | Soft Annealed (O60), Half Hard (H02), Hard (H04) |
| International Standards | ASTM B152, ASTM B272, EN 1652, JIS C1220, ISO 9001 |
Q1: What is the main difference between C12000 and C11000 copper sheets?
A: C12000 is Phosphorus-Deoxidized (DHP) copper containing residual phosphorus, which prevents hydrogen embrittlement during high-temperature welding or brazing. C11000 is Electrolytic Tough Pitch (ETP) copper with higher electrical conductivity (100% IACS), ideal for electrical busbars, but susceptible to embrittlement when heated in hydrogen environments.
Q2: Can C12000 copper sheets be cold bent and stamped easily?
A: Yes, in Soft Annealed (O60) or Half Hard (H02) tempers, C12000 copper sheet exhibits superior ductility, making it easy to bend, stamp, and deep draw without cracking.
Q3: What is your Minimum Order Quantity (MOQ) for custom sheared C12000 sheets?
A: Our standard MOQ for custom cut-to-size C12000 sheets is 300 kg. Standard warehouse sizes can be shipped in smaller trial batch quantities immediately.
If you require specific sheet thicknesses, CNC laser cutting service, or technical datasheets, explore our full range of Copper Sheet Products or Contact Our Sales Engineering Team directly for a fast factory quotation.
Our materials support a wide range of construction and infrastructure projects
C12000 copper sheet is a phosphorus-deoxidized copper alloy with good electrical conductivity and excellent corrosion resistance, while C12200 contains a higher phosphorus content and is more commonly selected for applications requiring extensive welding or brazing. The appropriate grade should be selected according to the fabrication process and service requirements.
C12000 copper sheet provides excellent formability, reliable welding and brazing performance, and good corrosion resistance. These characteristics make it suitable for a wide range of industrial fabrication processes requiring consistent manufacturing quality.
C12000 copper sheet is commonly used to manufacture heat exchangers, condensers, cooling equipment, and other thermal management components where good thermal conductivity, corrosion resistance, and dependable fabrication performance are essential.
It offers excellent resistance to seawater corrosion and maintains strength in humid and salt-rich conditions.
No. Strength is achieved through strain hardening rather than heat treatment.
Yes. It provides excellent weldability for structural fabrication.
Yes, it is commonly applied in tanks and pressure equipment.
Yes. It provides higher strength compared with most non-heat-treated aluminum alloys.
Yes. Thickness, width and temper can be adjusted based on project demand.
