C12200 Copper Bar is a phosphorus-deoxidized copper material known for its excellent corrosion resistance, good thermal conductivity, and reliable fabrication performance. It provides dependable performance in demanding industrial environments while maintaining excellent joining characteristics.
Widely used in piping systems, HVAC equipment, industrial components, and engineering applications requiring corrosion resistance, durability, and long-term service reliability.
C12200 copper bar (UNS C12200 copper rod, DHP high-phosphorus deoxidized copper bar, Cu-DHP bright drawn copper rod, CW024A extruded bar, and solid hexagonal copper rod) is manufactured through continuous extrusion, cold drawing, centerless grinding, and bright protective atmosphere annealing. Engineered for heavy-duty electrical busbars, HVAC manifold blocks, forged plumbing fittings, heat exchanger connectors, and high-precision CNC machined components, C12200 copper bar offers high electrical and thermal conductivity, excellent cold headability, superior brazing weldability, and 100% resistance to high-temperature hydrogen embrittlement.
At XQJ Metal, we operate advanced horizontal continuous casting lines, heavy-duty hydraulic extrusion presses, precision cold drawing benches, optical centerless grinders, and bright annealing furnaces to manufacture premium C12200 copper bar and rod products conforming strictly to global engineering standards, including ASTM B187 (standard specification for copper bus bar, rod, and shapes), ASTM B133, EN 12163 (Cu-DHP / CW024A), JIS H3250 (C1220), and GB/T 4423 (TP2) specifications. We offer full cross-sectional profiles including Round Bars (OD 3mm to 150mm), Square Bars (5mm to 100mm), Hexagonal Bars (Hex 5mm to 80mm), and custom rectangular flat busbars, supplied in straight lengths up to 6 meters or custom cut-to-length blanks.
| Temper Designation | Standard Code & State | Profile & Size Range (mm / inch) | Tensile Strength (MPa) | Hardness (HB / HV) | Primary Engineering Applications |
| Soft Annealed (O60) | ASTM B187 UNS C12200 O60 | Round / Flat: 3mm to 150mm (0.118″ – 5.91″) | 200 to 250 MPa | 50 to 65 HB | Complex hot forging blanks, cold heading rivets, severe cold bending busbars & brazeable pipe fittings |
| Half Hard (H02) | ASTM B187 UNS C12200 H02 | Round / Hex / Square: 3mm to 120mm (0.118″ – 4.72″) | 260 to 320 MPa | 75 to 95 HB | General CNC turned parts, electrical switchgear contacts, valve stems, HVAC manifolds & threaded couplings |
| Full Hard (H04) | ASTM B187 UNS C12200 H04 | Round / Hex / Square: 3mm to 80mm (0.118″ – 3.15″) | 320 to 400 MPa | 100 to 120 HB | High-strength electrical studs, heavy-duty structural fasteners, wear rings & rigid electrode holders |
| Extruded As-Worked (M20) | EN 12163 Cu-DHP / CW024A | Large Round / Billets: 50mm to 150mm (1.97″ – 5.91″) | 220 to 290 MPa | 60 to 80 HB | Heavy chemical equipment shafts, forge stock, marine sea chest flanges & thick power distribution blocks |
Selecting the optimal copper alloy rod is critical for high-temperature joining, pressure sealing, and electrical reliability. C12200 copper bar provides distinct metallurgical benefits over standard electrolytic tough pitch copper rods (C11000):
To reduce machining scrap and accelerate manufacturing cycles, XQJ Metal delivers comprehensive value-added processing for C12200 copper bar orders:
Our heavy-duty C12200 copper bar products serve as essential conductive and structural raw materials across global engineering sectors:
To guarantee strict chemical composition, uniform mechanical hardness, and defect-free internal structure, XQJ Metal enforces rigorous Quality Assurance (QA) protocols for every C12200 copper bar shipment:
Q1: What is the main difference between C12200 copper bar and C11000 copper bar for machining and brazing?
A: C12200 is phosphorus deoxidized (Cu-DHP), making it completely immune to hydrogen embrittlement during high-temperature torch brazing and gas welding. While C11000 offers higher electrical conductivity (100% IACS vs 85% IACS), C12200 is superior for components requiring heavy flame brazing or welding.
Q2: Can XQJ Metal supply C12200 hexagonal or square copper bars cut to exact cut lengths?
A: Yes, we produce C12200 copper bars in round, hexagonal, square, and flat shapes, with precision saw-cutting services to supply cut-to-length blanks from 10mm up to 6000mm according to your exact drawing requirements.
To request real-time FOB/CIF spot prices, bar weight calculators, or CAD machining quotes for C12200 copper bar, Contact Our Copper Engineering Team today.
Our materials support a wide range of construction and infrastructure projects
C12200 copper bar is a phosphorus-deoxidized copper alloy with a slightly higher phosphorus content than C12000, providing improved weldability and brazing performance while maintaining good corrosion resistance and thermal conductivity. The appropriate grade should be selected according to the fabrication process and service requirements.
C12200 copper bar is designed to provide reliable performance during welding and brazing by reducing the risk of hydrogen embrittlement. This makes it a preferred material for fabricated components that require strong, durable joints and long-term service reliability.
C12200 copper bar is commonly used for valves, fittings, heat exchangers, refrigeration equipment, pressure-related components, and other industrial parts where corrosion resistance, dependable fabrication, and long service life are essential.
It offers excellent resistance to seawater corrosion and maintains strength in humid and salt-rich conditions.
No. Strength is achieved through strain hardening rather than heat treatment.
Yes. It provides excellent weldability for structural fabrication.
Yes, it is commonly applied in tanks and pressure equipment.
Yes. It provides higher strength compared with most non-heat-treated aluminum alloys.
Yes. Thickness, width and temper can be adjusted based on project demand.
